型号 | 强制关闭 | Operation Temperature(℃ ) | 强制打开 | 感温部极限温度 | ||||||
动作温度 | ||||||||||
Type | Constraint OFF | W | N | C | Constraint OFF | Max Temp of Sensor (℃ ) | ||||
| ON | OFF | ON | OFF | ON | OFF | |||||
| WP14D-L | - | (33) | 30±2 | 1.5-3.5 | (17) | 14±1.5 | 2.5-4 | - | 80 | |
| WP15.7C-LR | - | (35) | 32±2 | 2-4 | (18.7) | 15.7±1.5 | 2-4 | - | 55 | |
| WP16L-L | - | (32.3) | 30±2 | 2-4 | (18.5) | 16±1.5 | 2-4 | - | 80 | |
| WP17G-L | - | (32) | - | - | (19.8) | 17±1.5 | 2.7±1 | - | 55 | |
| WPF32A-LX | - | -11 ± 2 | -18 ±2 | -17±1.5 | -25±1.5 | -22 ±2 | -32±2 | - | 80 | |
| WPF32.5A-LX | YES | -16.5±1.5 | -24.5±1.5 | - | - | (-22) | -32.5±2 | - | 80 | |
| WPF33.6A-LX | - | -14±1.5 | -19±1.5 | - | - | - | -33.6±2.2 | - | 80 | |
| WPF32W-LQ | - | -10±1.5 | -17.5±1.5 | - | - | -22±2.5 | -32±2.5 | - | 80 | |
| WDF21T-L | YES | 6.5 ± 1.1 | -6 ± 2 | 6.5±1.1 | (-14) | 6.5±1.1 | -21±1.5 | - | 80 | |
| WDF24G-L1 | YES | 4±1 | -12±1.5 | - | - | 4±1 | -24±2 | YES | 80 | |
| WDF27-L1 | YES | 3±1 | -14±2 | - | - | 3±1 | -27±1.5 | YES | 80 | |
| WDF31C-L | YES | (3) | (-16.5) | 3 ± 1.5 | -23.5±1.5 | 3±1.5 | -31±2 | YES | 80 | |
| WSF-19.5A-L | YES | (7) | 1.5 ± 2.5 | -3.5±1.5 | -11±1.5 | (-10) | -19.5±2.5 | 5±2.5 | 80 | |
| WSF24E-L | YES | 1±2.5 | -9±2.5 | -5±1.5 | -16±1.5 | (-10) | -24±2.5 | 5±2.5 | 80 | |
| WSF24G-L | YES | 2.5±2 | - | -4.5±1.5 | -15±1.5 | - | <-24 | 5±2 | 80 | |
| WSF27.5S-L | YES | (1) | (-10.5) | -4 ± 1.5 | -17.5±1.5 | - | (-27.5) | 5±2.5 | 80 | |
