| PRODUCTION | ALLOY NO | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| KS D5301 JIS H3300 | ASTM B111 | ASTM B466 | BS2871 {PART2} | AS1752 | DIN17664 | DIN 86019 WL2.1972 | EEMUA 144 | MIL-T- 16420K | EN12449 | |
| Copper Nickel (90/10)tube/pipe | C7060T | C70600 | C70600 | CN102 | C70600 | CuNi10Fe 1Mn | CuNi10Fe 1.6Mn | 7060X | 706 | CW352H |
| Copper Nickel (70/30)tube/pipe | C7150T | C71500 | C71500 | CN107 | C71500 | CuNi30Mn 1FE | 771506 | CW354H | ||
| Copper tube/pipe, LWC, Pan cake coil | C1220T | C12200 | C102 | C12200 | ||||||
| Aluminium Brass tube/Pipe | C6870T C6871T C6872T | C68700 | CZ110 | C68700 | ||||||
| Brass tube/Pipe | C2700T | |||||||||
| Admiralty Brass tube/Pipe | C4430T | C44300 | ||||||||
Item | Alloy No. | Common Characteristics and Usage |
크롬동 | C18200 | - Resistance welding electrode - Copper alloy material containing 0.4 to 1.2% of Cr |
C18150 | ||
베릴륨동 | C17200 | - High tensile energizing parts, discharge machining, electrodes |
l Chemical Composition
Alloy No. | Cr | Si | Fe | Pb | Zr | Al | Be | Cu |
C18200 | 0.6~1.2 | 0.1 MAX | 0.1 MAX | 0.5 MAX | Balance | |||
